始于 1958 年的波兰 RELPOL S.A.，是欧洲工业界的继电器制造商，六十余载深耕不辍，已发展为拥有 4 大生产基地、总面积达 17500 平方米的企业。从波兰扎雷的总部出发，RELPOL 以 “经验、质量、长期客户满意度” 为核心优势，构建了覆盖工业自动化、电力电子、通讯、家电等多领域的产品生态，服务数万家企业用户。作为 Warsaw Stock Exchange（代码：RLP）上市公司，RELPOL 凭借稳定的品质表现与技术创新，斩获 BBJ、VDE、UL、CE 等多项国际认证，成为欧洲电气工程领域的标志性品牌。

继电器：电磁;SPDT;Ucoil：12伏直流;I接触点最大：30A

继电器类型

电磁

接触配置

SPDT

额定线圈电压

12伏直流

联系电流最大值。

30A

交流接点额定@R

(在电阻负载下)

30A / 240V 交流电

直流触点额定@R

(在电阻负载下)

30A / 14V 直流电

开关电压

最大110伏直流电，最大300伏交流电

继电器变体

工业

安装

印刷电路板

制造商系列

R30N

线圈电压最小值

9伏直流

线圈最大电压。

15.6伏直流

车体尺寸

32.5x27.6x20.5毫米

线圈电阻

160Ω

作时间

15毫秒

释放时间

10毫秒

接触电阻

30mΩ

接触材料

农业之家2

线圈功耗

0.9W

IP等级

IP64

电流额定值

30A

工作温度

-55......100°C
